1 Channel CV DMX Dimming Driver Special for Dimming 12/24V DC

1 Channel CV DMX Dimming Driver Special for Dimming, 12/24V DC, 12A ×1CH + 0-10V×1CH + 10V PWM x 1CH, 144W/288W

811-12A

Qty: Order Item Add to Wishlist

LTECH is a front-runner in the field of LED lighting controller. As the first high-end manufacturer in China and one of the leading suppliers in the world, they have engaged in R&D of LED lighting control technology since 2001. As an intelligent lighting technology enabler, LTECH has developed hundreds of intelligent LED controlling technologies, which creates a more efficient, energy-saving, healthy and comfortable lighting life. Widely applied to the global lighting industry, innovative produc Show More...
To Follow
Quick Spec
Brief Description1 Channel CV DMX Dimming Driver Special for Dimming 12/24V DC
Colour FinishWhite
Item Nett Weight (kg)0.15kg
Length (mm)175mm
Width (mm)44mm
Height (mm)30mm
Protection ClassN/A
DimmableYes - Suitable Dimmer Required
Dimmer IncludedNo
IP RatingIP20
Warranty (yrs)5yrs
Features
Features, Will be added soon
Full Specifications
Collection GroupDMX Constant Voltage
Barcode5056037129332
Brief Description1 Channel CV DMX Dimming Driver Special for Dimming 12/24V DC
Colour FinishWhite
Item Nett Weight (kg)0.15kg
Length (mm)175mm
Width (mm)44mm
Height (mm)30mm
Type of DriverConstant Voltage
Dimming Range (%)0-100%
Power Factor (?)N/A (±5%)
Constant Voltage Output (V)12/24V DC
Max. Current Output (A)12A (12A x 1CH)
Load Range (W)144/288W
Connection TerminalScrew Terminal
Dimming ProtocolDMX512/RDM
EfficiencyN/A
Protection ClassN/A
Total Power Consumption (W)288W (±5%)
Input Voltage (V)12-24V DC
DimmableYes - Suitable Dimmer Required
Dimmer IncludedNo
IP RatingIP20
Warranty (yrs)5yrs
UKCA/CEYes
RohsYes
SELVN/A
EMV/EMCYes
Number of Cartons1
Carton Length (cm)17.8cm
Carton Width (cm)4.8cm
Carton Height (cm)3.3cm
Carton CBM0.0002
Carton Nett Weight (kg)0.15kg (±5%)
Carton Gross Weight (kg)0.16kg (±5%)
UK Commodity Code8543709990
Country of OriginChina
